Pitch dimensions are shown in millimeters, as the catalog states them.
- Hole shape
- Square
- Hole size
- 5x5 mm
- Approx. imperial
- 0.197 x 0.197″
- Open area
- 9.8%
- Open area band
- Low (Under 11%)
Square perforation
5x5mm
9.8% open area
The least open of the range. Chosen where the face has to read as close to solid as possible and acoustic absorption is a secondary concern.
Square holes on a straight grid, for a more graphic face at close range.
Specifying this pattern
Name it as 5x5mm at 9.8% open. The size alone is not enough to identify a pattern: this range holds two patterns at 1.8mm, two at 2.3mm, two at 2.5mm, two at 3mm and two at 5mm, and within each pair only the open area differs.
Perforation is available plain or perforated on our panel systems. Whether this pattern can be run on a particular panel depends on the panel size and its edge detail, so confirm it with us before it goes in a specification.
Data are approximated into in/ft/gauge. See the SI unit catalog for exact measurement.
